Portable EV Charger- EV-C90is
- Max AC Output VA : 9000
- *Rated AC Output VA : 75500
- Starting System : Recoil Start
- Fuel Consumption : Petrol 1.35 ltr/hr, Approx.
- Run time : 4.5 Hrs Approx.
- Rated Current Amps : 32
- NFB Amps : 32
Discription
This is a petrol fuel run 9 KVA portable power source to charge your EV- Cars. This EV charger is very useful for charging EV cars in emergency situations, when conventional charging systems are unavailable or fails. This is a very compact and portable charger and can be easily carried in your EV car. It's weight is just 58 kg only.
Product Information
- *Max AC Output VA : 9000
- *Rated AC Output VA : 7500
- Starting System : Recoil Start
- Fuel Consumption : Petrol 2.5 ltr/hr, Approx.or LPG : 1.3kg/hour
Generator & Alternator:
*Max AC Output VA : 9000
*Rated AC Output VA : 7500
Rated Current Amps : 32
NFB Amps : 32
AC. Voltage : 230 Volts ± 1%, 50 Hz ± 1%, Single Phase, THD < 2%
Alternator Type : Multi-Phase – Permanent Magnet (22 Pole) – Self Excitation
Inverter : 100 KHz, IGBT Based Digital Inverter – 9 Kw
Engine:
Model : HM192Pi
Type : OHV25°Inclined, Single Cylinder,4 Strokes, S.I, Forced Air Cooling
Maximum Power : 16.0HP @ 3600rpm
Bore x Stroke : 92x67 mm
Displacement : 445cc
Starting System : Recoil Start + Self start
Fuel : Petrol
Fuel Tank Capacity : Petrol – 25 Ltr.
Fuel Consumption : Petrol2.5 ltr/hr, Approx. or LPG : 1.3kg/hour
Lube. Oil Capacity : 1200 ml.
Lubricating Oil Consumption : 4.3 gm/Hr
Sound level (dB) (from 1 meter) : <86dB
Continues Running (With One Filling) : 10 Hrs. Approx (Petrol ) or 10 Hrs per LPG Cylinder
Panel & Other Standard Features:
AC Voltmeter - AC Amps- Hz Meter : Yes, Multifunction Digital Meter Provided
AC Output Sockets : Yes, 2 nos, Sockets- 50Amps, 25 Amps
Multifunction Digital Meter & Indicator : Digital Control Panel (V, Hz, Amp)
Oil Alert System : Yes
Over Load Indicator : Yes
Fuel Level Gauge : Yes
Paralleling Capability : Yes (Optional )
AC On /Off, Overload Protection (NFB) : Yes
Over Load Protection (NFB): Yes, 2 Circuits Breaks Provided
Ac Output Indicator : Yes
Packing:
Weight Appprox (Kg) : 58 Kg
Dimension LxWxH (mm) : 610 L x 520 W x 570 H
Battery Specification : Lithium Battery 12.8V- 15 Ah
Specifications are for reference only, Because of continuous improvements and up-gradation by our R&D team. This specifications can change without any prior intimation.
