7 KVA Portable Generator, Petrol Run, Model HP-9500E, Recoil & Self Start

₹74500 ₹120185

  • *Max AC. Output VA: 7000
  • *Rated AC. Output VA: 6000
  • Starting System : Recoil & Self Start
  • Fuel Consumption : Petrol 3.2 Ltr/Hr. Approx.
  • Run time: 6.5 hr. Approx

Special Highlight :

  • Low Priced & Economical Generator.
  • Powerful 7 KVA Portable Generators, Runs 2 Ton Air Conditioner + Other Loads.

Application :

  • light tower of fire fighting vehicle , OBM Vans, Advertising &Display Vehicle, Ambulance, Rescue applications, lighting tower, running air condition 2 ton many field application For running heavy loads.
  • General Purpose Portable Generator, suitable for household, offices, Nursing Homes & Restaurants, Banks & ATMs, Field Jobs etc.

This Premium product is the Outcome of excellent Hard work of HPM's R&D Engineers. Himalayan Power is a more than 25-year company that offers Complete Power & Lighting Solutions through > 300 Products & Models. HPM is a 100% Make in India Company with after Sales & Services & spare parts at very economical prices.

Product Information

  • *Max AC. Output VA : 7000
  • *Rated AC. Output VA : 6000
  • Rated Current Amps : 26
  • NFB Amps : 27
  • AC. Voltage at Rated Load : 225 Volts ± 10 Volt 50 Hz, Single Phase
  • AC. Voltage at No Load: 225 Volts ± 10 Volt

Alternator

  • #Alternator Max. Current Capacity : 30 Amps.
  • Alternator : Self-Excitation & Constant Voltage (With AVR),THD ≤ 25 %

Engine

  • Engine Model : HM192PY
  • Type : OHV25°Inclined,single cylinder, 4 strokes, S.I, Forced air cooling
  • Maximum Power : 16.0 hp @ 3600rpm
  • Bore x Stroke : 92×67 mm
  • Displacement : 445 cc
  • Starting System : Recoil Start + Self Start + Remote Start
  • Fuel : Petrol
  • Fuel Tank Capacity : Petrol -20.5 Ltr.
  • Fuel Consumption : Petrol: 3.2 Ltr./hr.
  • Continues Running (With One Filling) : 6.5 Hrs.
  • Lube. Oil Capacity : 1200 ml.
  • Lubricating Oil Consumption : 4.3 gm./Hr.
  • Sound level (Db) (from 1 meter) : <86Db

Panel & Other Standard Features

  • Voltmeter : Yes (Digital)
  • Digital Hour Meter : Yes
  • Oil Alert System : Yes
  • LPG/ Gas Fuel Compatibility : Yes (Optional)
  • AMF Panel Auto & Remote Start Compatibility : Yes
  • Fuel Level Gauge : Yes
  • Overload Protection (NFB) : Yes
  • Costar Wheels : Yes

Size & Weight

  • Approx. Weight (Kg) : 89 KG
  • Dimension LxWxH (mm) : 670 x 510 x 670 mm
  • Battery Specification : 12V -13Ah Lithium Iron Phosphate Battery

Warranty

Warranty Summary

  • *1 Year or 500 hrs standard manufacturing warranty on Engine and Alternator whichever is earlier

Service Type

  • Authorized Service Center or on Site by Visiting Service Engineer as Per Nature of Complaint

Covered in Warranty

  • *1 Year or 500 hrs standard manufacturing warranty on Engine and Alternator whichever is earlier

Not Covered in Warranty

  • NO WARRANTY ON PHYSICAL DAMAGES, ANY OF THE ELECTRONIC SPARES IN GENERATOR, AND EVERY DAY USABLE ITEM.
