4 KVA Petrol Inverter Generator , Recoil Start, Model Oasis UL-40i-EV,

₹56100 ₹90487

  • *Max AC. Output VA: 4000
  • *Rated AC. Output VA: 3800
  • DC Output : 5V-20V DC Panel
  • QC:3.0 USB Port
  • PD:3.0 Type C USB
  • Starting System : Recoil Start
  • Fuel Consumption: Petrol 1.5 Ltr./Hr. / LPG: 850 Gm. Approx
  • Run time:hr. Approx
  • Pure Sine Wave
  • Paralleling AC Output : 8KVA (2 x UL-40i-EV)

Special Highlight :

  • Gives a Stable Regulated voltage 230 ± 1% and Stable Frequency 50 Hz ± 1 % & Pure Sine Wave, THD < 2%
  • 4 KVA Genset, Ultra-Light Weight, Digital Invertor Based Alternator, Electronic Governor keeps Low Engine RPM at part loads for low fuel consumption.
  • To get more Power to Run Heavy Equipment, 2 or More HP 40i Generator can be made to Run In Parallel, Two HP40i Generators in Parallel will produce 4 KVA + 4 KVA = 8KVA Power

Application :

  • Being Light Weight and Portable Genset, It is very suitable for serving electrical requirements in remote areas / Field applications and running of sensitive Electronic Products Like Laptops / Computers / Digital Appliances, For charging Inverters, for all types of Frequency & Voltage sensitive Equipment’s, Military & Powering Defense Equipment’s Etc.

This Premium product is Outcome of excellent Hard work of HPM's R&D Engineers. Himalayan Power is more than 25-year company offers Complete Power & Lighting Solutions through > 300 Products & Models. HPM is a 100% Make in India Company with after Sales & Services & spare parts at very economical prices.

Product Information

  • *Max AC. Output VA    :  4000
  • *Rated AC. Output VA  :  3800
  • Rated Current Amps   :   16.5
  • NFB Amps   :   17
  • AC. Voltage    :     230 Volts ± 1%, 50 Hz ± 1%, Single Phase, THD < 2%
  • Alternator Type  :  Multi-Phase – Permanent Magnet (18 Pole) – Self Excitation
  • Invertor  : 100 KHz, IGBT Based Digital Invertor – 4 Kw

DC Outputs

  • DC Outputs - 5V to 20 V & DC Ports
  • USB Output (1 to 2)  :    2* 5V DC, 2.4 A (12W Per Port)
  • USB Output Fast Charging QC 3.0 (3)    :    1* 5V - 12V DC (18W-Max)  5V3A, 9V 2A, 12V 1.5A
  • Type - C USB (4)   :  1* 'C' Type - 1* USB C PD 2.0 (30W)  5V 3A, 9V 3A, 12V 1.5A 15 V 1.5A 20 V 1.5A

Engine

  • Model  :  HM170P
  • Type   :    OHV25°Inclined, Single Cylinder,4 Strokes, S.I, Forced Air Cooling
  • Maximum Power   :   6.5 HP @ 3600
  • Bore x Stroke   :   70x58 mm
  • Displacement  :   223 cc
  • Starting System : Recoil Start
  • Governor   :       Electronic Governor (Load Sensitive – Variable Speed)  Engine RPM 2200 (No Load) to 3800 RPM (at Full load)
  • Fuel  :      Petrol or LPG (Optional)
  • Fuel Tank Capacity   :        Petrol -7 Ltr.
  • Fuel Consumption     :       Petrol 1.5 ltr/hr, Approx. LPG: 850gm
  • Lube. Oil Capacity    :        600 ml.
  • Lubricating Oil Consumption      :   2.5 gm./Hr.
  • Sound level (Db) (from 1 meter)  :  <86Db (as per CBCP - II Norms)
  • Continues Running (With One Filling)   :    5 Hrs. Approx.

Panel &  Other Standard Features

  • Multifunction Digital Meter & Indicator   :    Digital Control Panel (V, Hz, Amp)
  • Oil Alert System  :   Yes
  • Over Load Indicator   :      Yes
  • 2 Genset Paralleling Capability   : Yes, Red & Black Pair of Sockets Provided in Control Panel for Paralleling of 2 Generators
  • LPG/ Gas Fuel Compatibility   :  Yes
  • AMF Panel Auto & Remote Start Compatibility    :  Yes (Optional)
  • Fuel Level Gauge    :    Yes
  • AC On /Off, Overload Protection (NFB)  :   Yes
  • Electronic Over Load Protection :   Yes, Inbuilt with Inverter

Packing

  • Weight Appprox (Kg)   :    33 Kg
  • Dimension LxWxH (mm)   :    532mm x 312mm x 525mm

Specifications are for reference only, Because of continuous improvements and up-gradation by our R&D team. This specifications can change without any prior intimation

Warranty

Warranty Summary

  • *1 Year or 500 hrs standard manufacturing warranty on Engine and Alternator whichever is earlier

Service Type

  • Authorized Service Center or on Site by Visiting Service Engineer as Per Nature of Complaint

Covered in Warranty

  • *1 Year or 500 hrs standard manufacturing warranty on Engine and Alternator whichever is earlier

Not Covered in Warranty

  • NO WARRANTY ON PHYSICAL DAMAGES, ANY OF THE ELECTRONIC SPARES IN GENERATOR, AND EVERY DAY USABLE ITEM.
