200 Amps, Portable Welding Generator, Model HPW-250-TIG, Petrol Run, Recoil Start

₹107850 ₹137633

  • DC Welding Output: 75 to 200 Amps
  • Electrode Dia.: 2.6mm to 4mm (E 7018)
  • *AC. Output VA: Invertor 1200 VA – 220 Volt AC, 50 Hz (Optional)
  • Fuel Consumption: Petrol 1.1 Ltr./Hr. Approx
  • Starting System: Recoil Start
  • Run time: 15 hr. Approx

Special Highlight:

  • World’s Most Portable, Professional & Low Cost Arc Welding Machine Suitable for High Class Welding Including Structural Welding Rods 7018 Size 4mm Electrode
  • Inbuilt 200 Amps, TIG Welding for “SS Welding, SS Pipe Lines”.

This Premium product is Outcome of excellent Hard work of HPM's R&D Engineers. Himalayan Power is more than 25-year company offers Complete Power & Lighting Solutions through > 300 Products & Models. HPM is a 100% Make in India Company with after Sales & Services & spare parts at very economical prices.

Product Information

  • Maximum Output (Duty Cycle 60%): 200 Amps.
  • Welding Output at 100 % duty Cycle :175 Amps
  • Working Voltage for Arc Welding : 20v to 32v
  • Working Voltage for Tig Welding : 15V - 20V
  • Open Circuit Voltage : 70 Volt (Maximum)
  • Current Regulation Amps​ : *75-200
  • Rectifying Mode : SCR, Phase Controlled 3-phase, Rectifying Bridge
  • Maximum Electrode diameter (MMA) : 2.6 mm to 4.0 mm (E 7018)
  • Alternator Type :Multiphase, Brush less with Rear Earth Magnet Rotor
  • Class of Insulation : F



Above Specifications are for reference only, Because of continuous improvements and up-gradation by our R&D team.  This specification’s can change without any prior intimation

Size & Weight

Dimension LxWxH (mm) : 790 x 510 x 670 mm Dry Weight (Kgs.): 82 Kg

Panel & Other Standard Features

Aux. AC Output 230 Volt - 50 Hz : Invertor 1200 VA – 220 Volt AC, 50 Hz (Optional) A.C. Circuit Protector (NFB) : Yes  A C. Pilot Lamp​ : Yes Engine Oil Protection : Yes (Electronic Oil Alert & Indicator) Fuel Level Gauge: Yes A.C. Output Sockets : Yes (1 Nos.) Costar Wheels & Handles : Yes

Optional Accessories

Sheet Metal Welding Attachment (Helps to adjust low current upto 75 Amps.) : 1 Kit (Additional Cost)

Standard Accessories

AC Plug : 1Pcs. Tool Kit : 1 Set Welder Holder : 1 Set Earthing Clamp with 3Mtr. Cable : 1 Set Oil Funnel : 1 No Owner’s Manual : 1 No  Tig Torch with Cable : 1 Set

Engine

Model : HM170FB Type : Single Cylinder Air-cooled; 4-stroke, OHV 25˚ Inclined Maximum Power :7.5 HP Bore x Stroke : 70x58 Displacement : 223cc Starting System : Recoil Start  Ignition System : TCI (Transistor Control Ignition) ​Fuel : Standard Petrol Fuel Tank Capacity : 15.5 Liters Fuel Consumption # Ltr./Hr. : 1.1Ltr./hr. Continuous Operating Hour : 15 hr. Lube. Oil Capacity : 600 ml. Lubricating Oil Consumption : 2.5 gm./Hr.

Above Specifications are for reference only, Because of continuous improvements and up-gradation by our R&D team.  This specification’s can change without any prior intimation

Maximum Output (Duty Cycle 60%): 200 Amps. Welding Output at 100 % duty Cycle :175 Amps Working Voltage for Arc Welding : 20v to 32v Working Voltage for Tig Welding : 15V - 20V Open Circuit Voltage : 70 Volt (Maximum) Current Regulation Amps​ : *75-200 Rectifying Mode : SCR, Phase Controlled 3-phase, Rectifying Bridge Maximum Electrode diameter (MMA) : 2.6 mm to 4.0 mm (E 7018) Alternator Type :Multiphase, Brush less with Rear Earth Magnet Rotor Class of Insulation : F

Size & Weight

Dimension LxWxH (mm) : 790 x 510 x 670 mm Dry Weight (Kgs.): 82 Kg

Panel & Other Standard Features

Aux. AC Output 230 Volt - 50 Hz : Invertor 1200 VA – 220 Volt AC, 50 Hz (Optional) A.C. Circuit Protector (NFB) : Yes  A C. Pilot Lamp​ : Yes Engine Oil Protection : Yes (Electronic Oil Alert & Indicator) Fuel Level Gauge: Yes A.C. Output Sockets : Yes (1 Nos.) Costar Wheels & Handles : Yes

Optional Accessories

Sheet Metal Welding Attachment (Helps to adjust low current upto 75 Amps.) : 1 Kit (Additional Cost)

Standard Accessories

AC Plug : 1Pcs. Tool Kit : 1 Set Welder Holder : 1 Set Earthing Clamp with 3Mtr. Cable : 1 Set Oil Funnel : 1 No Owner’s Manual : 1 No  Tig Torch with Cable : 1 Set

Engine

Model : HM170FB Type : Single Cylinder Air-cooled; 4-stroke, OHV 25˚ Inclined Maximum Power :7.5 HP Bore x Stroke : 70x58 Displacement : 223cc Starting System : Recoil Start  Ignition System : TCI (Transistor Control Ignition) ​Fuel : Standard Petrol Fuel Tank Capacity : 15.5 Liters Fuel Consumption # Ltr./Hr. : 1.1Ltr./hr. Continuous Operating Hour : 15 hr. Lube. Oil Capacity : 600 ml. Lubricating Oil Consumption : 2.5 gm./Hr.



Warranty

Warranty Summary

  • *1 Year or 500 hrs standard manufacturing warranty on Engine and Alternator whichever is earlier

Service Type

  • Authorized Service Center or on Site by Visiting Service Engineer as Per Nature of Complaint

Covered in Warranty

  • *1 Year or 500 hrs standard manufacturing warranty on Engine and Alternator whichever is earlier

Not Covered in Warranty

  • NO WARRANTY ON PHYSICAL DAMAGES, ANY OF THE ELECTRONIC SPARES IN GENERATOR, AND EVERY DAY USABLE ITEM.
