1 KVA Petrol Inverter Generator, Model Oasis UL-10i , Recoil Start

₹19600 ₹25383

  • *Max AC. Output VA: 1000
  • *Rated AC. Output VA: 750
  • DC Output : 5V-20V DC Panel
  • 12V-12amps CG port
  • QC : 3.0 USB Port
  • PD  :3.0 Type C USB
  • Starting System : Recoil Start
  • Fuel Consumption: Petrol 0.50 Ltr./Hr. Approx
  • Run time: 2.5hr – 3hr. Approx
  • Pure Sine Wave

Special Highlight :

  • World most light Weight & Most Fuel Efficient 850 VA Genset, Just Weighs: 18Kg
  • Also Runs On LPG Cylinder & Produce Electricity At Most Economical Price.

Application :

  • Most Useful for Army Posted at Hilly Terrain and Snowy hilly tops. (Soldiers Can Carry on their Shoulders)
  • Due To Light Weight Ideal for Field Jobs and Mobile Applications, Picnic Camp Application.

This Premium product is the Outcome of excellent Hard work of HPM's R&D Engineers. Himalayan Power is a more than 25-year company that offers Complete Power & Lighting Solutions through > 300 Products & Models. HPM is a 100% Make in India Company with after Sales & Services & spare parts at very economical prices.

Product Information

  • *Max AC. Output VA  :   900
  • *Rated AC. Output VA  :    750
  • Rated Current Amps :  3.3
  • NFB Amps  :  3.5
  • Rated AC. Voltage  :  230 Volts ± 1%, 50 Hz ± 1%, Single Phase, THD < 2%
  • #Alternator Max. Current Capacity  :  6 Amps.
  • Alternator  :   Brushless, Permanent Magnetic Alternator with PSW inverter Technology

DC Outputs

  •  DC 12 V – 100 Watt, CG Port
  • Continuous Output Current  :     8 A (Max. 100 Watt)
  • DC Outputs - 5V to 20 V & DC Ports
  • DC Output Short-circuit Protection  :   Yes (Disconnect Load Recovery)
  • 12V DC Output Over Load Current Protection :    Yes >8 A (Disconnected Load Recovery)
  • USB Output Fast Charging QC 3.0   :  1* 5V - 12V DC (18W-Max)  5V3A, 9V 2A, 12V 1.5A
  • Type - C USB  :   1* 'C' Type - 1* USB C PD 2.0 (30W)  5V 3A, 9V 3A, 12V 1.5A 15 V 1.5A 20 V 1.5A

Engine

  •  Model  :  GE 152P
  • Type  :  Side Valve, vertical, single cylinder,4 strokes, S.I, Forced air cooling
  • Maximum Power  :   1.4Kw/3600rpm
  • Bore x Stroke  :  52mm×46mm
  • Displacement  :   97.6cc
  • Starting System : Recoil Start
  • Fuel    :    Petrol
  • Fuel Tank Capacity   :   Petrol -1.4 Ltr.
  • Fuel Consumption   :  0.50 ltr/hr, approx. (At rated Load)
  • Lube. Oil Capacity   :  350 ml.
  • Lubricating Oil Consumption   :   ≤6.5g/kW .h
  • Continues Running (With One Filling)   :  Approximately 2.5 - 3 Hrs.
  • Sound level (Db) (from 1 meter) : <86Db

Panel & Other Standard Features

  • Voltmeter  :  Yes (Analogue)
  • Output Indicator   :    Yes
  • Over Load Indicator  :   Yes
  • Digital Hour Meter  :  No
  • Oil Alert System :   Yes
  • LPG/ Gas Fuel Compatibility  :   Yes (Optional)
  • AMF Panel Auto & Remote Start Compatibility  :    No
  • Fuel Level Gauge   :  No
  • Overload Protection (NFB)    :  Yes

Packing

  • Approx. Weight  : 18 Kg
  • Dimension LxWxH (mm)   :   360x356x400

Specifications are for reference only, Because of continuous improvements and up-gradation by our R&D team. This specifications can change without any prior intimation



Warranty

Warranty Summary

  • *1 Year or 500 hrs standard manufacturing warranty on Engine and Alternator whichever is earlier

Service Type

  • Authorized Service Center or on Site by Visiting Service Engineer as Per Nature of Complaint

Covered in Warranty

  • *1 Year or 500 hrs standard manufacturing warranty on Engine and Alternator whichever is earlier

Not Covered in Warranty

  • NO WARRANTY ON PHYSICAL DAMAGES, ANY OF THE ELECTRONIC SPARES IN GENERATOR, AND EVERY DAY USABLE ITEM.
