1 KVA Petrol Inverter Generator, Model Oasis UL-10i , Recoil Start
- *Max AC. Output VA: 1000
- *Rated AC. Output VA: 750
- DC Output : 5V-20V DC Panel
- 12V-12amps CG port
- QC : 3.0 USB Port
- PD :3.0 Type C USB
- Starting System : Recoil Start
- Fuel Consumption: Petrol 0.50 Ltr./Hr. Approx
- Run time: 2.5hr – 3hr. Approx
- Pure Sine Wave
Special Highlight :
- World most light Weight & Most Fuel Efficient 850 VA Genset, Just Weighs: 18Kg
- Also Runs On LPG Cylinder & Produce Electricity At Most Economical Price.
Application :
- Most Useful for Army Posted at Hilly Terrain and Snowy hilly tops. (Soldiers Can Carry on their Shoulders)
- Due To Light Weight Ideal for Field Jobs and Mobile Applications, Picnic Camp Application.
This Premium product is the Outcome of excellent Hard work of HPM's R&D Engineers. Himalayan Power is a more than 25-year company that offers Complete Power & Lighting Solutions through > 300 Products & Models. HPM is a 100% Make in India Company with after Sales & Services & spare parts at very economical prices.
Product Information
- *Max AC. Output VA : 900
- *Rated AC. Output VA : 750
- Rated Current Amps : 3.3
- NFB Amps : 3.5
- Rated AC. Voltage : 230 Volts ± 1%, 50 Hz ± 1%, Single Phase, THD < 2%
- #Alternator Max. Current Capacity : 6 Amps.
- Alternator : Brushless, Permanent Magnetic Alternator with PSW inverter Technology
DC Outputs
- DC 12 V – 100 Watt, CG Port
- Continuous Output Current : 8 A (Max. 100 Watt)
- DC Outputs - 5V to 20 V & DC Ports
- DC Output Short-circuit Protection : Yes (Disconnect Load Recovery)
- 12V DC Output Over Load Current Protection : Yes >8 A (Disconnected Load Recovery)
- USB Output Fast Charging QC 3.0 : 1* 5V - 12V DC (18W-Max) 5V3A, 9V 2A, 12V 1.5A
- Type - C USB : 1* 'C' Type - 1* USB C PD 2.0 (30W) 5V 3A, 9V 3A, 12V 1.5A 15 V 1.5A 20 V 1.5A
Engine
- Model : GE 152P
- Type : Side Valve, vertical, single cylinder,4 strokes, S.I, Forced air cooling
- Maximum Power : 1.4Kw/3600rpm
- Bore x Stroke : 52mm×46mm
- Displacement : 97.6cc
- Starting System : Recoil Start
- Fuel : Petrol
- Fuel Tank Capacity : Petrol -1.4 Ltr.
- Fuel Consumption : 0.50 ltr/hr, approx. (At rated Load)
- Lube. Oil Capacity : 350 ml.
- Lubricating Oil Consumption : ≤6.5g/kW .h
- Continues Running (With One Filling) : Approximately 2.5 - 3 Hrs.
- Sound level (Db) (from 1 meter) : <86Db
Panel & Other Standard Features
- Voltmeter : Yes (Analogue)
- Output Indicator : Yes
- Over Load Indicator : Yes
- Digital Hour Meter : No
- Oil Alert System : Yes
- LPG/ Gas Fuel Compatibility : Yes (Optional)
- AMF Panel Auto & Remote Start Compatibility : No
- Fuel Level Gauge : No
- Overload Protection (NFB) : Yes
Packing
- Approx. Weight : 18 Kg
- Dimension LxWxH (mm) : 360x356x400
Specifications are for reference only, Because of continuous improvements and up-gradation by our R&D team. This specifications can change without any prior intimation
