5.5 KVA Portable Generator, Petrol Run, Model HP-6500, Recoil Start

₹49400 ₹79721

  • *Max AC. Output VA: 5500
  • *Rated AC. Output VA: 5000
  • Starting System : Recoil Start
  • Fuel Consumption : Petrol 2.8 Ltr/Hr. Approx.
  • Run time: 7.5 hr. Approx

Special Highlight :

  • Powerful 5.5 KVA Portable Generators, Runs 1.5 Ton Air Conditioner + Other Loads.
  • Low Priced & Economical Generator.

Application :

  • General Purpose Portable Generator, suitable for household, offices, Nursing Homes & Restaurants, Banks & ATMs, Field Jobs etc.



This Premium product is the Outcome of excellent Hard work of HPM's R&D Engineers. Himalayan Power is a more than 25-year company that offers Complete Power & Lighting Solutions through > 300 Products & Models. HPM is a 100% Make in India Company with after Sales & Services & spare parts at very economical prices.

Product Information

  • *Max AC. Output VA : 5500
  • *Rated AC. Output VA : 5000
  • Rated Current Amps : 21.8
  • NFB Amps : 22
  • AC. Voltage at Rated Load : 225 Volts ± 10 Volt 50 Hz, Single Phase
  • AC. Voltage at No Load: 225 Volts ± 10 Volt

Alternator

  • #Alternator Max. Current Capacity : 24 Amps.
  • Alternator : Self-Excitation & Constant Voltage (With AVR),THD ≤ 25 %

Engine

  • Engine Model : HM192PY
  • Type : OHV25°Inclined,single cylinder, 4 strokes, S.I, Forced air cooling
  • Maximum Power : 16.0 hp @ 3600rpm
  • Bore x Stroke : 92×67 mm
  • Displacement : 445 cc
  • Starting System : Recoil Start
  • Fuel : Petrol
  • Fuel Tank Capacity : Petrol -20.5 Ltr.
  • Fuel Consumption : Petrol: 2.8Ltr./hr.
  • Continues Running (With One Filling) : 7.5 Hrs.
  • Lube. Oil Capacity : 1200 ml.
  • Lubricating Oil Consumption : 4.3 gm./Hr.
  • Sound level (Db) (from 1 meter) : <86Db

Panel & Other Standard Features

  • Voltmeter : Yes (Analogue)
  • Digital Hour Meter : No
  • Oil Alert System : Yes
  • LPG/ Gas Fuel Compatibility : Yes (Optional)
  • AMF Panel Auto & Remote Start Compatibility : Yes
  • Fuel Level Gauge : Yes
  • Overload Protection (NFB) : Yes
  • Costar Wheels : Yes

Size & Weight

  • Approx. Weight (Kg) : 77 KG
  • Dimension LxWxH (mm) : 672 x 530 x 680 mm

Warranty

Warranty Summary

  • *1 Year or 500 hrs standard manufacturing warranty on Engine and Alternator whichever is earlier

Service Type

  • Authorized Service Center or on Site by Visiting Service Engineer as Per Nature of Complaint

Covered in Warranty

  • *1 Year or 500 hrs standard manufacturing warranty on Engine and Alternator whichever is earlier

Not Covered in Warranty

  • NO WARRANTY ON PHYSICAL DAMAGES, ANY OF THE ELECTRONIC SPARES IN GENERATOR, AND EVERY DAY USABLE ITEM.
